Also searched as: fire roller shutter operator, fire door motor, fail-safe fire door drive OEM
A fire door operator automates fire-rated rolling and sliding doors that compartment smoke and flame — and its defining requirement is fail-safe behaviour: on alarm or power loss the door must close reliably and stay closed, while normal daily operation still meets safe force limits for people nearby. Fire-rated rolling-door motors are a recognized specialist product class in the operator industry: established rolling-door motor makers list dedicated fire rolling-door motors alongside their AC and DC lines [SOURCED: jielongmotor.com].
RAX Door Technology manufactures fire door operators matched to EI60 / EI120 fire-rated door systems, built on an in-house servo motor assembly line and validated in a 100,000-cycle fatigue test lab. Control logic supports fail-close release on fire-alarm signal, with anti-pinch safety edge and bottom air-bag sensor options for everyday safe use, and WiFi / RS485 connectivity for building-management integration. As a pure manufacturer (no on-site installation), we engineer the operator to your fire door’s weight, travel and certification route, then ship from prototype to full production runs — full flexibility on order quantity — with wiring diagrams and English manuals under full OEM/ODM terms.
Fire-alarm input and power-loss release logic so the door closes reliably when it matters; controlled-close behaviour for daily use [ESTIMATE — confirm logic per project].
Engineered for EI60 / EI120 fire-rated rolling and sliding door systems; fire classification of the installed assembly is verified per project to EN 1634-1 practice.
Anti-pinch safety edge, bottom air-bag sensor and force limits aligned to the EN 12453 / EN 12978 framework for powered doors.
ISO 9001:2015 and CE to EN 13241 / EN 12453, SGS material reports; AS/NZS 4505 and UL counterpart test data can be supported.
| Product | Fire Door Operator (fail-safe drive for fire-rated rolling shutters and sliding fire doors). |
| Door compatibility | Fire-rated roller shutters and sliding fire doors; operator matched to door weight, travel and rated assembly. Specialist fire rolling-door motors are a standard product class in this market [SOURCED: jielongmotor.com]. |
| Fire rating of system | EI60 / EI120 fire-rated door systems available; fire classification of the complete installed assembly is engineered and tested per project (EN 1634-1 practice) [ESTIMATE]. |
| Fail-safe function | Close-on-alarm input; gravity or controlled descent on power loss; optional battery backup for retained control [ESTIMATE — confirm configuration per order]. |
| Supply / motor voltage | 230 V AC supply common on heavy/industrial drives [ESTIMATE]; 24 V DC variants for safety-critical and battery-backed duty [SOURCED: familyhandyman.com]. Confirm variant per order. |
| Control & connectivity | Fire-alarm dry-contact input; RF remote; WiFi / RS485 remote options for BMS integration; radar / geomagnetic / light-curtain sensing inputs available. |
| Safety | Anti-pinch safety edge, bottom air-bag sensor option; forces and protective devices aligned to EN 12453 / EN 12978 frameworks. |
| Materials / build | Galvanized steel housing, aluminum alloy 6063-T5 components; full RAL custom color (common RAL9006 / 9010 / 7016 / 5010). |
| Certification | CE: EN 13241 (door system) + EN 12453 (operator safety). Fire resistance of the door assembly per EN 1634-1 confirmed per project [ESTIMATE]. |
| Warranty / service | Operator/motor 3 years, servo motor 5 years; free spare parts within warranty via DHL/FedEx (5–7 days). |
| Order | Custom engineered to your exact opening, specification and RAL color |
Figures marked [ESTIMATE] are industry-typical conventions, not RAX test data; fail-safe logic and fire-rating data for your assembly are confirmed per inquiry. RAX figures are from the approved brand brief.
Door type (roller shutter / sliding), weight, width × height and rated assembly — the basis for torque matching and technical drawing confirmation.
Required EI class (EI60 / EI120) and your fire-alarm signal type; we engineer the close-on-alarm logic and release behaviour to match.
230 V AC or 24 V DC, battery backup needs and the required behaviour on power loss (close / hold / controlled descent).
Cycle frequency for normal operation, safety edge / air-bag / light-curtain inputs, and any BMS integration via WiFi / RS485.
RAX supports full private-label production of fire door operators: custom colors, operator matching to your fire-door line, packaging printing and installation-manual translation (EN/ES/FR/AR/RU). Start with an OEM sample and scale to container-load branded production. Custom molds, Tooling records are archived for up to 5 years — no extra tooling fee on repeat orders, all under strict NDA (27-year zero-leak record). Standard lead time 12–20 days per container; FOB Tianjin / Qingdao, FCL & LCL supported.
Product standard for industrial, commercial and garage doors and gates — crushing/shearing protection, safe force levels, EMC; the harmonized basis for CE marking.
Safety in use of power-operated doors — requirements and test methods for powered doors where people have access.
Fire-resistance test method for door assemblies; the EI60 / EI120 classification of the complete installed fire door is verified per project [ESTIMATE].
Design and testing of protective devices (safety edges, contact strips) and mechanical test methods referenced by EN 13241.
The operator accepts a fire-alarm dry-contact input and closes the door reliably; on power loss the configured fail-safe behaviour (gravity or controlled descent, with optional battery backup) takes over [ESTIMATE — confirmed per project]. Daily operation keeps full anti-pinch and safety-edge protection.
RAX supplies EI60 / EI120 fire-rated door systems matched to this operator. Fire classification is a property of the complete installed assembly and is engineered and verified per project to EN 1634-1 practice [ESTIMATE] — send your specification and we confirm the route.
RAX holds ISO 9001:2015 and CE to EN 13241 (industrial door) and EN 12453 (operator safety), with SGS material reports and product liability insurance. Fire-resistance data for the door assembly is arranged per project; AS/NZS 4505 (Australia) and UL (North America) counterpart test data can be supported.
Yes. A dry-contact fire-alarm input is standard practice, with WiFi / RS485 connectivity options for building-management integration and RF remotes for authorized daily use. Confirm signal types with our engineers on technical drawing.
Yes. Color, operator matching to your fire-door line, packaging printing and manual translation (EN/ES/FR/AR/RU) are all supported, from an OEM sample to container-load branded production, under NDA with tooling archived up to 5 years.
Sample 7–15 days; standard container 12–20 days; custom first order 20–35 days (repeat 15–20). Operator/motor warranty is 3 years (servo motor 5 years), with free spare parts dispatched by DHL/FedEx within warranty (5–7 days).
Or email info@raxdoor.com
Send your door type, weight, opening size and required fire rating — we reply with a fail-safe matched proposal and lead time.
