Vertical Lifting Fabric Door

Space-Saving · Up to 1 m/s CE · EN 13241 Full technical drawings

01 · Overview

Vertical Operation for Limited Headroom

Vertical lifting fabric doors operate by lifting the curtain vertically into a compact housing above the opening, requiring minimal headroom compared to sectional doors that need overhead space for panel stacking. This makes them ideal for facilities with limited ceiling height or where overhead space is occupied by cranes, conveyors, or storage systems.

RAX manufactures vertical lifting fabric doors with reinforced PVC or fabric curtains, heavy-duty track systems, and servo motor drive. Opening speeds up to 1 m/s minimize energy loss during frequent access. Wind resistance rated to Class 3 (700 N/m²) with reinforced bottom bars and side guides.

These doors are essential for warehouses with limited headroom, industrial facilities with overhead obstacles, and any application where vertical operation is preferred over horizontal sliding or sectional operation.

Get a Free Quote

02 · Key Features

Engineered for Vertical Operation

Vertical Lifting Design

Curtain lifts vertically into compact housing above the opening. Requires minimal headroom (approximately door height + 300 mm). No overhead space needed for panel stacking. Ideal for facilities with limited ceiling height.

High-Speed Operation

Opening speeds up to 1 m/s with servo motor drive. Frequency converter for smooth acceleration/deceleration. Minimizes energy loss during frequent access cycles.

Reinforced Curtain Construction

Heavy-duty PVC or fabric curtains with reinforced bottom bar. Wind resistance Class 3 (700 N/m²) with side guides and brush seals. Durable construction withstands high-cycle industrial use.

Compact Housing

Curtain rolls into sealed housing above the opening. Protects curtain from dust and damage when open. Maintains clean appearance in finished facilities.

Safety Systems

Photocells, pressure-sensitive bottom edge, emergency stop. Compliant with EN 12453. Optional light curtains for enhanced personnel protection in high-traffic areas.

Smart Control

PLC-based control with LCD display. Programmable speeds, delay times. Remote operation and diagnostics. Integration with BMS and WMS systems.

Get a Free Quote

03 · Technical Data

Technical Specifications

Photocells, pressure-sensitive bottom edge, emergency stop

CE EN 13241 / EN 12453 (held); ISO 9001:2015; SGS material reports

Custom engineered to your opening size and specification

Product	Vertical Lifting Fabric Door (also: Vertical High Speed Door · Compact High Speed Door)
Category	Industrial Doors
Curtain material	Reinforced PVC or heavy-duty fabric
Opening speed	Up to 1 m/s (adjustable)
Closing speed	Up to 0.8 m/s (adjustable)
Motor type	Servo motor with frequency converter
Headroom required	Door height + ~300 mm (housing)
Wind resistance	Class 3 (700 N/m²) per EN 12424
Width range	1,500–6,000 mm (custom)
Height range	1,500–6,000 mm (custom)
Safety features
Certification
Order

Get a Free Quote

04 · Applications

Where Vertical Lifting Doors Excel

Warehouses with Limited Headroom

Facilities with low ceilings or overhead obstacles. Vertical lifting requires only door height + 300 mm headroom. No overhead space needed for panel stacking. Maximizes usable ceiling space.

Industrial Facilities with Overhead Cranes

Manufacturing plants with overhead crane systems. Vertical lifting doors operate below crane rails. No interference with crane operation. Maintains full crane coverage.

Facilities with Conveyor Systems

Distribution centers with overhead conveyors. Vertical lifting doors install below conveyor lines. No modification to conveyor systems required.

Multi-Story Buildings

Upper-floor loading docks with limited overhead space. Vertical lifting doors fit within floor-to-ceiling constraints. Compact housing maintains building aesthetics.

Cold Storage with Low Ceilings

Freezers and chillers with limited headroom. Fast operation minimizes cold air loss. Insulated curtain options available for temperature control.

Retrofit Applications

Existing facilities where overhead space is occupied. Vertical lifting doors install without modifying existing infrastructure. Minimal construction required.

Get a Free Quote

05 · Customization

OEM / ODM & Customization

RAX supports full private-label production of the Vertical Lifting Fabric Door: custom curtain material, RAL color matching, motor specification, control system programming, packaging printing and installation-manual translation (EN/ES/FR/AR/RU). Start with an OEM sample and scale to container-load branded production. Custom molds and tooling records are archived for up to 5 years — no extra tooling fee on repeat orders, all under strict NDA.

Get a Free Quote

06 · Compliance

Applicable Standards

EN 13241:2003+A2:2016

Core CE product standard for industrial, commercial, and garage doors. Covers both manual and powered doors. Requires Declaration of Performance (DoP) under CPR 305/2011.

EN 12453:2001

Safety requirements for powered doors. Specifies force limiting, safety devices, and control system requirements.

EN 12424:2000

Wind load resistance classification. Defines Classes 0–5. Vertical lifting doors typically achieve Class 3 (700 N/m²).

CE Marking

Mandatory for export to EU/UK markets. RAX provides CE technical file and Declaration of Performance with every shipment.

Get a Free Quote

07 · Why RAX

Why Buyers Choose RAX for Vertical Lifting Doors

27-year zero-leak track record — 5,000+ overseas projects delivered since 1999, with no leakage complaints on door bodies
Minimal headroom — only door height + 300 mm required, ideal for space-constrained facilities
High-speed operation — up to 1 m/s minimizes energy loss during frequent access
Compact housing — curtain rolls into sealed housing, protecting from dust and damage
Deep customization — every door engineered to your exact size, specification, and application requirements
Full documentation package — English installation manual, wiring diagrams, CE technical file

Get a Free Quote

How much headroom do vertical lifting doors require?

Only door height + approximately 300 mm for the housing. Significantly less than sectional doors that require overhead space for panel stacking. Ideal for facilities with limited ceiling height.

What is the opening speed?

Up to 1 m/s opening speed, 0.8 m/s closing speed. Speed is adjustable via PLC control system. Servo motor with frequency converter ensures smooth operation.

Can these doors install below overhead cranes?

Yes. Vertical lifting doors operate below crane rails. No interference with crane operation. Maintains full crane coverage. Ideal for manufacturing plants with overhead crane systems.

What safety features are included?

Photocells, pressure-sensitive bottom edge, emergency stop. Optional light curtains. All compliant with EN 12453 safety requirements for powered doors.

Do you provide installation?

No — RAX is a pure manufacturer. Doors ship with English installation manuals, wiring diagrams, and remote support.

What is the lead time and warranty?

Standard configurations: 12–20 days. Custom first order: 20–35 days. Repeat orders: 15–20 days. Warranty: curtain 10 years, motor and control 5 years.

09 · Get Started

Get Your Vertical Lifting Fabric Door Proposal

Send your opening size, headroom measurement, and application type — we reply with a specification, lead time, and quote.
